Haefely PCD 121 Coupling Network

Coupling Network for Symmetrical Data and Control Lines

The PCD 121 is used for coupling of 1,2/50us – 8/20us combination wave impulses up to 6.6kV peak onto unshielded symmetrical data and signal lines according IEC/EN standards. Up to 2 pairs / 4 wires can be tested simultaneously.

Haefely Hipotronics
File-PDF-iconEnglish Version
Category: Tags: ,
Richiedi Informazioni
  • Combination wave 1,2/50us – 8/20us impulse
  • Serial resistors included
  • Up to 2 pairs / 4 wires can be tested
  • Signal Bandwidth up to >10MHz
  • Low capacitive load on the EUT lines
  • Manual coupling path selection
