- 1MHz to 2700MHz frequency range
- Resolution bandwidths of 1MHz, 280kHz or 15kHz
- -96dBm typical noise floor at -20dBm reference level
- Measurement in dBm or dBuV, mV or uW
- Zero span mode with AM and FM audio demodulation
- Trace modes of normal, peak hold and trace average
- Live, View and Reference traces in contrasting colours
- Twin markers with readout of absolute & difference values
- Smart marker movement with selectable peak tracking
- Frequency presets and independent state storage
- Auto-find automatically sets sweep parameters for the highest signal found
- Unlimited storage for waveforms, set-ups and screens
- User file names, file stamping from real-time clock
- USB interfaces for Flash drives and PC connection
- Comprehensive status and context sensitive help screens
- More than 8 hours continuous operation from a charge
- Smaller and lighter than other spectrum analyzers (weight only 20 oz)
** Additional features – with option U01:-
- Limit lines and limit patterns with limits comparator
- Data logging of peak values, complete traces or screen images from timer, external trigger or limits comparator
- Level offsets and compensation tables
- Sweep triggering from external trigger or limits comparator
- Custom Presets – fast change for repetitive setups
- Capability to show screen contents on a PC
