- Nominal Frequency Range 0.7…10 GHz
- Isotropic Gain 5 … 13 dBi (f > 1 GHz)
- Antenna Factor 25 … 39 dB/m (f > 1 GHz)
- Nominal Impedance 50 Ω
- Standing Wave Ratio SWR typical 2
- Standing Wave Ratio SWR max. < 3 (f > 1.25 GHz)
- Port Isolation typ. > 30 dB
- Cross Polarisation typ. > 25 dB
- 3 dB Beamwidth typ. (E-Plane) 40-80°
- 3 dB Beamwidth typ. (H-Plane) 40-140°
- Max. Input Power 100 W (intermitt.)
- 50 W (cont.)
- SMA-Connector female
- Mount flange plate with 4 holes f 6.2 mm in square, drill spacing 75 mm
- Width x Length x Height 235 x 200 x 235 mm
- Weight 0.84 kg
- Option Mounting Tube 220 x 22 mm
Antenne Horn EMC - Compatibilità elettromagnetica
Richiedi Informazioni
Schwarzbeck CTIA 0710 Dual Polarized Broadband Horn Antenna
The Schwarzbeck CTIA 0710 Dual Polarized Broadband Horn Antenna is a linear polarized dual double ridged broadband antenna for receive and transmit applications made of aluminium.
